Steering System

View:

SD-1091E

• To remove fast and easily worn tie rods and install new tie rods with a 27mm spanner or 1/2″ ratchet wrench

• Special head design grips tie rod end firmly by turning clockwise and anti-clockwise

• Application range Ø35-45 mm, mainly for European passenger cars

• Overall length with only 195 mm, suitable for working in limited spaces

• Tool NOT designed to be used with an air/impact wrench

SD-1091

• To remove fast and easily worn tie rods and install new tie rods with a 27mm spanner or 1/2″ ratchet wrench

• Special head design grips tie rod end firmly by turning clockwise and anti-clockwise

• Application range Ø35-45 mm, mainly for European passenger cars

• Tool NOT designed to be used with an air/impact wrench

SD-1091B

• To remove fast and easily worn tie rods and install new tie rods with a 27mm spanner or 1/2″ ratchet wrench

• Special head design grips tie rod end firmly by turning clockwise and anti-clockwise

• Application range Ø28-35 mm, suitable for small European and Japanese cars

• Tool NOT designed to be used with an air/impact wrench

SD-1107

• For removing and installing bushings and bearings

• Equipped with sleeve sizes from 34-66mm (ID) and 44-82mm (OD) with 2mm increments

• Includes 4 spindles with two 27mm hex nuts: M10 x P1.5, M12 x P2.0, M14 x P2.0 and M16 x P2.5

• Provided with two step discs with two sides (A and B sides). Discs have tracks for fitting all sleeves, without needing several individual step discs

• Tool NOT designed to be used with an air/impact wrench

SD-1105

• For removing and installing bushings and bearings

• An accessory set for SD-1101, SD-1102 and SD-1104

• Sizes: 62-80mm (ID) and 70-88mm (OD)

• Long sleeves are 110mm in length and short sleeves are 40mm in length

• Suitable for trucks

SD-1104

• For removing and installing bushings and bearings

• Hydraulic cylinder provides energy- and time-saving removing and installing works

• Includes 4 spindles: M10 x P1.5, M12 x P1.75, M14 x P2.0 and M16 x P2.0

• Sleeve sizes: 18-60 mm (ID) and 26-68 mm (OD) with 2 mm increments

• Universal application

SD-1102

• For removing and installing bushings and bearings

• Hydraulic cylinder provides energy- and time-saving removing and installing works

• Includes one M20 × P2.5 spindle

• Sleeve sizes: 18-60 mm (ID) and 26-68 mm (OD) with 2 mm increments

• Universal application

SD-1101

• For removing and installing bushings and bearings

• Hydraulic cylinder provides energy- and time-saving removing and installing works

• Includes 4 spindles: M10 × P1.5, M12 × P1.75, M14 × P2.0 and M16 × P2.0

• Sleeve sizes: 18-60 mm (ID) and 26-68 mm (OD) with 2 mm increments

• Universal application
